Power supply: battery powered
Operating voltage range: DC 9V – 95V
Operating current: 12V/average 40mA Sleeping
Current: 12V/less than 10mA built-in
Battery capacity: 140 mAh (3.7V polymer rechargeable battery) Option
Positioning module brand/chip model: Zhongke Micro AT6558R
Cold start time: average 32 seconds
Hot start time: 1 sec. average
Sensitivity (tracking): -162DBM
Positioning antenna: Built-in antenna
Appearance size: 90.6mm * 57mm * 20mm
Housing material: ABS plastic
IP Protection Grade: IP67
Main body weight: 68g
Electric Motorcycle Positioning Terminal
Model: GT02A
1.4G full network pass, support 4G version, 2G version, support global.
2.GPS+Beidou+LBS tri-mode positioning.
3. Fireproof and drop-proof, IP67 waterproof, military grade technology.
4. 4. Wide voltage design, support DC 9V – 95V.
5. Communication module brand/chip model EC25/EC200/UC200.
6. SIM card: micro SIM card
7. Communication antenna: Built-in antenna Network type: cat 1/cat m/nb cat 1/cat m/nb
Application areas: private car, enterprise fleet, public transportation, official car, finance leasing car, electric car.
